AZ623 ADSL Modem Router 4FE 2.4G WIFI

1* ADSL + 4FE + 2.4G WIFI / external antennas

♦ Support Bridge/IPoE/PPPoE/PPPoA/IPoA Internet access, IPv4/IPv6 Dual stack, Wizard, PVC
auto search, ADSL mode
♦ WiFi4 basic functions/advanced configuration, Guest network, Black and white list
♦ Wireless Encryption WEP/WPA/WPA2, WPS , 802.1X
♦ Password management, Device management, Configuration management, Upgrade management, Log function, Status statistics, Restart /reset
♦ DMZ, ALG, Virtual server, Port trigger, Advanced NAT, Port binding, DDNS, UPnP, ATM QoS, IP QoS, Static routing, RIP, 6RD/DS-Lite tunnel, IGMP/MLD, Diagnostic test
♦ Safety Function Anti DoS attack, MAC filter, IP/port filter, URL Filter, ACL access control

💬 WhatsApp 📞 Contact Us

The AZ623 provides integrated 802.11n technology with up to 24mbps downlink ADSL2 speed and 1Mbps uplink 1Mbps. The highest wireless transmission rate is 300mbps. It provides WEP data encryption and WPA / WPA2 wireless security, and status packet inspection (SPI) firewall protection. Priority queues and packets allow your home to experience streaming without worrying about congestion.

ParameterSpecification
Main ChipsRTL8676S+RTL8271B+RTL8192E
Flash4MB SPI NOR
Memory16MB SDRAM SOC
Wireless ProtocolIEEE 802.11b/g/n
Wireless Transfer RateWiFi: 2.4G=300Mbps
ADSL2+: uplink 1Mbps, downlink 24Mbps
FR Index2.4G 11N HT40 MCS7=16dBm(+/-2dB)
External Interface4*LAN 10/100Mbps
1*ADSL
1*DC JACK
Indicator LightsPower, DSL, INT, LAN1-4, WLAN, WPS
Buttons1*PWR
1*WPS
1*Reset
1*WLAN
Antennas2*2.4G 5dBi fixed external antennas
Power AdapterDC 12V 0.5A
TemperatureOperating Temperature: 0 ℃ to +40℃
Storage Temperature: -20 ℃ to +70 ℃
HumidityOperating Humidity: 10% to 95% non-condensing
Storage Humidity: 5% to 95% non-condensing
Dimensions204mm*120mm*32mm
Weight210g
CertificatesMeet CE certification standards
Order Information[AZ623] 1*AD 4*LAN
WAN ConnectionSupport Bridge/IPoE/PPPoE/PPPoA/IPoA Internet access, IPv4/IPv6 Dual stack, Wizard, PVC auto search, ADSL mode
Wireless FunctionWiFi4 basic functions/advanced configuration, Guest network, Black and white list
Wireless EncryptionWireless Encryption WEP/WPA/WPA2, WPS, 802.1X
System MaintenancePassword management, Device management, Configuration management, Upgrade management, Log function, Status statistics, Restart / reset
Advanced FunctionDMZ, ALG, Virtual server, Port trigger, Advanced NAT, Port binding, DDNS, UPnP, ATM QoS, IP QoS, Static routing, RIP, 6RD/DS-Lite tunnel, IGMP/MLD, Diagnostic test
Safety FunctionAnti DoS attack, MAC filter, IP / port filter, URL Filter, ACL access control
Software SystemOSK
